Medela Healthcare has over 50 years of experience in producing innovative and safe medical vacuum technology. All of our products are engineered and manufactured to quality you would expect of a Swiss company. Our products are used by doctors and healthcare professionals all over the world, enabling them to care for their patients in an effective and efficient way.

Vario 18

Features and Benefits:

AC(240-0021) | AC/DC (240-0022) | AC/DC C/I (Constant/Intermittent)
Quatro-Flex Technology	Rapid vacuum build-up
Membrane Vacuum Regulator	Accurate vacuum setting
Locking Dial	Patient safety
Quiet, small & lightweight	Unobtrusive and portable operation
Unobtrusive and portable operation	Included at no charge
AC/DC Only (240-0022)
Battery	Operate from wall, battery or a 12V car connection
Constant/Intermittent	Affords options. Intermittent – 8 on – 4 off, 16 on – 8 off, 32 on – 16 off second intervals

Specifications:

High Vacuum	-75kPa, -563mmHg
Low Flow	18 l/min
Weight	18 l/min
Dimensions	9.5" x 14.6" x 18.5" (shipping)
IPX1	Protection from dripping water
Vacuum Gauge	kPa & mmHg
Warranty	2 Year limited warranty, 6 months for QuatroFlex & battery
AC/DC Only (240-0022)
Battery	Charges during use
Battery Run Time	Fully charged, 30 minutes
Battery Charge Warning	Optical & Acoustic
Operates From	Wall, Battery or 12V car adapter
AC/DC C/I
Battery Run Time	Fully charged, 30 minutes
Battery Charge Warning	Optical & Acoustic

Return to Top | Request for Demo | Order Medela Products



---

Basic 30

Features and Benefits:

Mobile with Cart(240-0023) | Portable(240-0024)
Piston/Cylinder Technology	Rapid vacuum build-up
Membrane Vacuum Regulator	Precise suction performance
Portable or Mobile Modality	Greater flexibility
Portable Size	Fits most endoscopy towers/systems
Drive System	Quiet
Safety Set in Front	Prevents overflow and contamination within pump
Design	Based on years of research and experience

Specifications:

High Vacuum	-85kPa, -638mmHg
High Flow	30 l/min
Power	100-120VAC, 110W, 60Hz
Weight - Pump	26.5 lbs.
Weight - Trolley	20.7 lbs.
Dimensions - Pump	16.5" x 15.8" x 12.6" (shipping)
Dimensions - Trolley	26.4" x 19.3" x 8.7" (shipping)
Protection Class II	Without a protective earth. Double insulated to prevent electric shock.
Potential Equalization Conductor	Maintains the difference in potential at 0, thus preventing any transfer of static electricity running through the patient.
IP21	Protection from dripping water
Vacuum Gauge	kPa & mmHg
Warranty	5 Years

Return to Top | Request for Demo | Order Medela Products | Click Here for Basic 30 Basic Setup | Click Here for Brochure



---

Dominant 50

Features and Benefits:

Mobile with Cart(240-0019) | Portable(240-0020)
Piston/Cylinder Technology	Rapid vacuum build-up & quiet operation
Membrane Vacuum Regulator	Precise suction performance
Portable or Mobile Models	Greater flexibility
Drive System	Quiet
Safety Set on Side	Prevents overflow and contamination within pump
Design	Based on years of research and experience
Suitable for suctioning of large quantities of fluids and liposuction	Large volume collection & liposuction

Specifications:

High Vacuum	-90kPa, -675mmHg
High Flow	50 l/min
Power	100-120VAC, 150W, 60Hz
Weight - Pump	29.3 lbs.
Weight - Trolley	20.7 lbs.
Dimensions - Pump	16.5" x 16.1" x 13.8" (shipping)
Dimensions - Trolley	26.4" x 19.3" x 8.7" (shipping)
Protection Class II	Without a protective earth. Double insulated to prevent electric shock.
Potential Equalization Conductor	Maintains the difference in potential at 0, thus preventing any transfer of static electricity running through the patient.
IP21	Protection from dripping water
Vacuum Gauge	kPa & mmHg
Warranty	5 Years

Return to Top | Request for Demo | Order Medela Products | Click Here for Dominant 50 Basic Setup | Click Here for Brochure



---

Filtration: When aspirating materials (to draw or remove by suction), aerosols are produced that contain bacteria. These aerosols can contaminate, corrode, or deteriorate fittings, pipes, pumps and regulators. This equipment then becomes colonized with potentially pathogenic microorganisms that can both reduce vacuum efficiency and result in cross contamination (the passing of bacteria, microorganisms or other harmful substances indirectly from one patient to another through improper or unsterile equipment, procedures, or products).

Item #	Description	Image	Uses	UOM
116-5478	Disposable overflow protection/bacteria filter with Medela connections		Prevents overflow and protects from bacteria	10 /Pkg

Return to Top | Request for Demo



---

Pump by Application
